Quadratic Relations

Quadratic Relations
Recall - Linear Relations
Linear relations is a special types of relationship between two variables
- When the value of the independent variable changes, the value of the dependent variable changes by a proporationate amount
- In a table of values representing a linear relation, we will see constant first differences
- In an equation representing a linear relation, we will see a degree of 1 for both independent and dependent variables
- In a graph represending a linear relation, we will see a straight line

But what if a relation is not linear, are there other types of special relations?
Paper Airplane Experiment

A paper plane is launched into the air. The following table shows the height of this plane at different points in time. Create a scatter plot and sketch the curve of best fit for this experiment.


What are some special features of this relation?
- Shape of the curve of best fit:
- If we extend the graph beyond 0, into the negative time values, we notice the curve of best fit is symmetric.
- Is the dependent variable increasing or decreasing?
- The curve of best fit increases as before time reaches 1.5 seconds, then it decreases at the same rate.
- If we extend the curve of best fit, what do we know about its intercepts?
- The curve of best fit crosses the y-axis once, so there is one y-intercept. But if we extend the curve, we see that it crosses the x-axis twice, so there are two x-intercepts.
- What do you notice about the first and second differences from the table of values?
- The first differences are not constant, but the second differences are constant

Quadratic Relation
Two variables are related and have a quadratic relation if it has the following properties:
- The graph of the relation is a parabola -- a symmetric "U" shape
- The table of value for this relation has a constant second difference that is not zero
- The equation of the relation has degree 2
Different Forms of the Quadratic Equation
A quadratic equation must have degree 2, but there are a few different possible forms:
- Standard form: y=ax2+bx+c
- Factored form: y=a(x−r)(x−s)
- Vertex form: y=a(x−h)2+k

Example: Quadratic Relation
Show that the following are quadratic relations. If the graph is not given, sketch the graph.
a)

The graph is a parabola ("U" shape). It is symmetrical along the y-axis, it is decreasing to the left of the y-axis and increasing to the right of the y-axis.
b)

Looking at this table of values, you can see that the y-values appear to be symmetric, but let's determine the second differences to be sure that this is a quadratic relation.

Since the second differences are constant, this does represent a quadratic relation.
Here is the graph of the relation:

c) y=−2(x+4)2−3
Let's first expand and simplify the expression:
yyyyyyyyyy=−2(x+4)2−3=−2(x+4)(x+4)−3=−2(x+4)(x+4)−3=−2[(x)(x)+(x)(4)+(4)(x)+(4)(4)]−3=−2[x2+4x+4x+16]−3=−2[x2+8x+16]−3=−2[x2+8x+16]−3=(−2)(x2)+(−2)(8x)+(−2)(16)−3=−2x2−16x−32−3=−2x2−16x−35
We see that this equation is of the form y=ax2+bx+c, it has degree 2. So, it is a quadratic relation.
Here's the graph for this relation:

Practice: Quadratic Relations
Select all of the situations that can be modelled with a quadratic relation.
