Non-Ohmic Resistors
A non-Ohmic resistor doesn't obey Ohm's Law . That is, the resistance is not constant.
This means that the graph of the voltage vs. the current is not a straight line.
Examples:
- Light bulb: as the temperature increases, the ions inside the hot filament move faster, slowing down the passing electrons, and therefore increasing the resistance.
- Diode: in a diode, the current flows only in one direction, because in the other direction the resistance is very high.
- LDR (light dependent resistor): as the intensity of the surrounding light increases, the resistance decreases (useful for automatically switchings lights on and off).
- Thermistor: as the temperature increases, the resistance decreases (useful for turning the heating system on and off).
