Valence Shell Electron Pair Repulsion Theory (VSEPR)

  • The VSEPR theory states that repulsion of electron groups (lone pairs and bonds) in the valence shell will determine the 3D geometry of a molecule.
  • In VSEPR theory, we focus on the number of electron groups around a central atom.
  • Bonding groups
  • Non-bonding groups
  • To draw a VSEPR structure, you need the Lewis structure and the number of electron groups.
  • Wedges mean the bond is coming out of the page
  • Dashes mean the bond is going into the page
  • We use all the electron groups to get the electron-pair geometry.
  • To get the molecular geometry, we look at the atoms present




Image illustrating Valence Shell Electron Pair Repulsion Theory (VSEPR)




Create a free account to get started

Unlock full course notes by signing up

  • Video lessons taught by top educators
  • Practice questions with guided solutions
  • Written review notes for reference
  • Expert answers anytime from course tutors

Example: VSEPR Shapes

Determine the electron pair arrangement and molecular geometry for NH3


Image illustrating Example: VSEPR Shapes


Electron geometry: tetrahedral

Molecular shape: trigonal pyramidal


Practice: VSEPR Terms and Definitions

The VSEPR model includes several concepts related to atomic theory. Match the following terms and definitions.

Match each term
A.

the outermost energy level or orbit of an atom or ion

B.

a shared pair of electrons

C.

a pair of electrons that is not involved in bonding

D.

all pairs of valence electrons repel each other

electron pair repulsion

lone pair

valence shell

bonding pair

Create a free account to get started

Unlock full course notes by signing up

  • Video lessons taught by top educators
  • Practice questions with guided solutions
  • Written review notes for reference
  • Expert answers anytime from course tutors

Practice VSEPR Shapes

For the following molecular geometries, fill in the table below with:

  • the total number of electron groups
  • the number of lone pairs on the central atom
  • the number of bonding groups


Molecular GeometryTotal number of electron groupsNumber of lone pairs around the central atomNumber of bonding groups
Linear
Trigonal Planar
Bent
Trigonal Pyramidal
Tetrahedral

Create a free account to get started

Unlock full course notes by signing up

  • Video lessons taught by top educators
  • Practice questions with guided solutions
  • Written review notes for reference
  • Expert answers anytime from course tutors

Practice: Determining Electron Pair Arrangement and Molecular Geometries

Use the VSEPR theory with the following molecules to answer the following questions.

  1. PF3
  2. NH4+
  3. H2S

Which molecule has a tetrahedral electron pair arrangement?

Choose an answer
