Lewis Dot Diagrams

  • Lewis dot diagrams are diagrams in which the valence electrons of an atom are shown as dots distributed around the element’s symbol.

Image illustrating Lewis Dot Diagrams


Bonds and Lewis Diagrams

  • We can use Lewis diagrams to show the formation of ionic compounds
Image illustrating Lewis Dot Diagrams
  • We also use Lewis diagrams to show the formation of molecular compounds. A line is used to indicate a shared pair of electrons. These diagrams are also known as Lewis structures or structural formulas
Image illustrating Lewis Dot Diagrams
  • Molecular compounds can have double (they share two pairs of electrons) and triple bonds (they three pairs of electrons). We show these using double or triple lines
Image illustrating Lewis Dot Diagrams


Create a free account to get started

Unlock full course notes by signing up

  • Video lessons taught by top educators
  • Practice questions with guided solutions
  • Written review notes for reference
  • Expert answers anytime from course tutors

Drawing Lewis Structures

Steps for Drawing Lewis Structures

Example: CCl4

  1. Calculate the total number of valence electrons for the molecule. If drawing the Lewis structure for a ion, subtract one electron per positive charge and add one electron per negative charge

C: 4 valence electrons

Cl: 7 valence electrons x 4 Cl atoms = 28 valence electrons

Total: 4 + 28 = 32 valence electrons for the molecule

  1. Write out all atoms, with the least electronegative atom in the middle

Image illustrating Drawing Lewis Structures

  1. Connect surrounding atoms to the central atom with single bonds.
Image illustrating Drawing Lewis Structures


  1. Place remaining electrons as lone pairs on surrounding atoms (except hydrogen), completing an octet around each atom

Remaining electrons: 32 - 4x2 = 24 electrons


Image illustrating Drawing Lewis Structures
  1. Place remaining electrons as lone pairs on the central atom.

Remaining electrons: 24 - 6x4 = 0

No electrons on central atom

  1. Shift lone pairs to make double or triple bonds to satisfy the octet rule for all atoms

All electrons have a full octet


Create a free account to get started

Unlock full course notes by signing up

  • Video lessons taught by top educators
  • Practice questions with guided solutions
  • Written review notes for reference
  • Expert answers anytime from course tutors

Example: Lewis Structures

Draw the Lewis structure of PCl3




Image illustrating Example: Lewis Structures







Create a free account to get started

Unlock full course notes by signing up

  • Video lessons taught by top educators
  • Practice questions with guided solutions
  • Written review notes for reference
  • Expert answers anytime from course tutors

Example: Drawing Lewis Structure with a Double Bond

Draw the Lewis structure for CO2.


Image illustrating Example: Drawing Lewis Structure with a Double Bond


Create a free account to get started

Unlock full course notes by signing up

  • Video lessons taught by top educators
  • Practice questions with guided solutions
  • Written review notes for reference
  • Expert answers anytime from course tutors

Example: Drawing Lewis Structures for Ions

Draw the Lewis structure for the BF4- ion.



Image illustrating Example: Drawing Lewis Structures for Ions


Practice: Periodic Table and Valence Electrons

Which group of the periodic table can most easily donate an electron in a chemical reaction?

Choose an answer

Create a free account to get started

Unlock full course notes by signing up

  • Video lessons taught by top educators
  • Practice questions with guided solutions
  • Written review notes for reference
  • Expert answers anytime from course tutors

Practice: Valence Electrons

Which molecule has the highest number of valence electrons?


Choose an answer

Create a free account to get started

Unlock full course notes by signing up

  • Video lessons taught by top educators
  • Practice questions with guided solutions
  • Written review notes for reference
  • Expert answers anytime from course tutors

Practice: Drawing Lewis Structures

Draw the Lewis structure for the following molecules, then use the Lewis structures you drew to answer the following questions.

  1. CH2O
  2. H3O+
  3. NH4+

Whose Lewis structure has double bonds?
